PRM 3000Va Single Phase Relay Type Electrical Automatic Ac Power Voltage Regulator With Surge Protection
Description
3000Va Single Phase Relay Type Electrical Automatic Ac Power Voltage Regulator With Surge Protection
Model |
PRM-3000 |
PRM-5000 |
Nominal Power |
3000VA |
5000VA |
Power Factor |
0.6-1.0 |
|
Input | ||
Operating Voltage Range |
125~285V |
|
Regulation Voltage Range |
140~260V |
|
Frequency |
50HZ |
|
Connection Type |
Power cord with plug |
|
Output | ||
Operating Voltage |
180~255V |
|
High Cut Voltage |
255V |
|
Low Cut Voltage |
180V |
|
Safety Cycle |
3 Seconds |
|
Frequency |
50HZ |
|
Connection Type |
Output socket |
|
Regulation | ||
Regulation % |
8% |
|
Number of Taps |
5 |
|
Transformer Type |
Toroidal auto transformer |
|
Regulation Type |
Relay type |
|
Indicators | ||
LED display |
Input voltage Output voltage Delay time Load usage Normal working Temperature of transformer Error code |
|
Protection | ||
Over Temperature |
Auto Shutdown at 120 ℃ |
|
Short Circuit |
Auto Shutdown |
|
Overload |
Auto Shutdown |
|
Over / Under Voltage |
Auto Shutdown |
|
Packaging information
Model |
Unit(PCS) |
Device Size(MM) |
Package Size(MM) |
G. W. (KGS) |
PRM-3000VA |
1 |
305*240*90 |
365*310*160 |
6.00 |
PRM-5000VA |
1 |
305*240*90 |
365*310*160 |
8. 00 |
The advantage of 3000Va Single Phase Relay Type Electrical Automatic Ac Power Voltage Regulator With Surge Protection PRM-3000-D:
1
Wide Input voltage: AC140~260V or customize
2. High technology: Programmed control computerized
3. Fashion design: LED display which can show all protection functions.
4. Quality insurance: Main spare parts made by ourselves, for example, transformer, PCB.
5. Perfect protection function: Over/low voltage protection, over-heat/load protection, short circuit protection.
6. Option Function: with voltage regulator and mains supply two kind output voltage choice function, in mains supply relatively stable season, the user can put voltage stabilizer in mains supply state, there is no power consumption, it is economic and convenient.
7. RJ45 connector Available, it adopt TEX, MODEM/TEL.
8. High efficiency: More than 95
HEYA
Introducing the PRM 3000Va Single Phase Relay Type Electrical Automatic Ac Power Voltage Regulator with Surge Protection.
The perfect solution to protect your valuable electrical devices from power fluctuations. Designed for households and small businesses who require a reliable voltage regulating tool that will protect their appliances from voltage sag swell and spikes.
Features a sleek yet robust design that exudes durability and sophistication. Made with high-quality HEYA materials this product boasts a long lifespan efficient performance and low maintenance. Its compact size and lightweight body make it easy to install saving you both time and money.
The regulator functions in an automatic mode which means it quickly and accurately regulates the voltage of your electrical devices without requiring any human intervention. Provides a stable voltage output and reduces the risk of electrical fires and damages to electronic devices such as computers refrigerators TVs and other household appliances.
With a surge protection capability that can prevent electrical devices from damage caused by power surges which can easily happen during electrical storms. Its advanced technology enables the product to identify isolate and eliminate an abnormal surge using its built-in surge suppressor without impairing the voltage regulation process.
Designed to provide safety and protection against overvoltage and under voltage to your electronic devices. Its adaptive voltage regulation feature ensures your appliances get the right voltage without being under-volted or over-volted. It has an output voltage range of 100-270V making it perfect for use in different power environments.
Upgrade your household or small business's voltage regulation system today.
